Kongsberg's compact, off-the-shelf HUGIN designed to be launched from uncrewed surface vessels, small boats, or shore.

HUGIN Edge is a compact member of Kongsberg's HUGIN AUV family, introduced in 2022 as the company's first off-the-shelf, fixed-configuration HUGIN. The 4.1 m, 350-390 kg vehicle dives to 1,000 m and runs for more than 24 hours, carrying the same class of HISAS synthetic aperture sonar and multibeam echosounder as its larger siblings in a smaller, faster-to-deploy package. It is designed to be launched and recovered from uncrewed surface vessels, small boats, or the shore, which makes it well suited to remote, low-carbon survey of offshore wind sites and cables, seabed mapping, and naval mine countermeasures.

Основные роли

Примечания

Kongsberg datasheet: 410 cm long, 43 cm high, 52 cm wide, 350-390 kg in air, 5-1,000 m operating depth, 24 hours at 3 kn, 2-5 kn (nominal 3.5-4 kn), battery swap in 2-3 hours or 8-hour charge. It is the first fixed-configuration 'off the shelf' HUGIN and is designed for deployment from USVs, small vessels, and shore.
